Cuav XB Radio Pro - 900MHZ 250mW 15KM Xbee Wireless Radio Telemetry for Pixhawk Pixhack Flight Controller

Cuav XB Radio Pro  xbee SPECIFICATIONS

Wheelbase: Bottom Plate

Upgrade Parts/Accessories: Adapter

Tool Supplies: Assembled class

Technical parameters: Value 9

Size: As description

Remote Control Peripherals/Devices: Receivers

Recommend Age: 12+y

RC Parts & Accs: Connectors/Wiring

Quantity: 1 pcs

Origin: Mainland China

Model Number: xbee

Material: Metal

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Airplanes

Cuav XB Radio Wireless Pro xbee Digital Flight Control System Pix / V5 + Flight Control Signal Transmission Accessories

Product introduction:
Cuav XB Radio Pro wireless data communication module provides best-in-class wireless connectivity for drones or IoT devices.
They use DigiMesh network protocol, which has intensive network operation andSupport for sleep routers, and can also adopt a proprietary point-to-multipoint configuration.
These modules support RF line-of-sight ranges up to 28 miles (with high-gain antennas) and data rates up to 200 Kbps, making them ideal for extended-range applications that require increased data throughput.
Cuav XB Radio Pro requires no programming and can be easily configured using Digi's free XCTU software or through a simplified AT command set.
The built-in Digi XBee module is pre-certified in multiple countries.
The XB Radio Pro module is easy to use, shares a common hardware serial port, and provides a variety of different protocols, allowing users to integrate into your drone or device with minimal development time and risk.



Product Features:

Double-ended switching:
Cuav XB Radio Pro has built-in TTL and USB ports. The air end and ground end are seamlessly switched design, which has greater flexibility and reduces the use cost.
Integrated RSSI output:
CUAV XB Radio PRO integrates signal strength output, which can be directly connected to the drone controller, so that users can obtain the current signal strength in real time, so as to judge the risk of loss of connection.



Specifications:

Hardware parameters:
Frequency range: 902 ~ 928 MHz
Processor: ADF7023 transceiver, Cortex -X3 EFM32G230 @ 28Mhz
Programmable includes: Freescale MC9s08QE32
Antenna selection: wire.U.FIL and RPSMSA



Performance:
Data rate: 10kbps / 200Kbps (depending on the firmware speed, the default is 200k)
City / Indoor distance: 10kbps: up to 2000 feet (610 meters); 200kbps: up to 1000 feet
Maximum power: 24dBM (250mw) software optional
Receiving sensitivity: -101dBM @ 200Kpds; -110dBm @ 10kbps



characteristic:
Data interface: UART (3V) .SPI
GPIO: 15 digital i0, 4 10-bit ADC inputs, 2 PWM outputs
Network topology: DIgiMEsh, relay, point-to-point, point-to-multipoint, peer-to-peer network
Spread spectrum: FHSS (software selectable)

Programmability:
Memory: 32kb FLASH / 2kb RAM
CPU clock: up to 50MHZ

power supply:
Power supply voltage: 4-7v
Emission current: 229mA
Receive current: 44ma
Sleep current: 3uA

Management agency certification:
FCC (US): MCQ-XB900HP
iC (Canada): 1846A- -XB900HP
C-tick (Australia): Yes
Anatel (Brazil): Yes
IDA (Singapore): Yes
