CaddxFPV Farsight Analog FPV Camera, 1/2 inch sensor, 1500TVL, CVBS, 1-8X PWM Smart Zoom, 19x19mm

$118.3
Quantity
ADD TO CART
BUY IT NOW
  • Detail

    Overview

    The CaddxFPV Farsight Analog FPV Camera delivers AI-assisted smart zoom for precise framing in demanding FPV use. A 1/2 inch image sensor, 4:3 output, and wide 122.5° FOV capture a broad, detailed scene, while the external AI box enables 1-8X fast zoom via PWM control with instant reset to 1x. CVBS analog output ensures broad compatibility with existing analog systems.

    Key Features

    • AI-assisted smart zoom: 1-8X fast magnification with smooth, real-time adjustment.
    • PWM control via flight controller; reset switch quickly returns to 1x magnification.
    • 1/2 inch sensor for improved light sensitivity; 4:3 aspect ratio and 122.5° FOV.
    • Analog CVBS video output; 1500TVL horizontal resolution.
    • Wide 9~24V input with low power draw (<2w); -20℃~60℃ operating range.
    • Compact camera unit: 19x19x19.5mm; separate AI Box: 33.5x33.5x12.35mm.

    Specifications

    ModelCaddx Farsight
    Image Sensor1/2 inch
    Illuminance0.01Lux
    Focal Length2.2mm
    FOV122.5°(H) x 92.2°(V) x 155°(D)
    Horizontal Resolution1500TVL
    Aspect Ratio4:3
    Zoom Ratio1-8X
    Zoom ModeConnect to FC, PWM Control
    Video InterfaceCVBS
    Power Supply Range9~24V
    Power Consumption<2w
    Operating Temperature-20℃~60℃
    DimensionsCamera: 19x19x19.5mm; AI Box: 33.5x33.5x12.35mm

    What’s Included

    • Farsight (camera + AI box) x1
    • Quick Start Guide x1
    • 7Pin3 silicone cable x1
    • 3Pin silicone cable x1
    • 6mm screws x2
    • 5mm screws x2
    • 4mm screws x2
    • Screw washers x2

    Applications

    • FPV flights where variable framing is required
    • Wildlife observation
    • Industrial inspection
    • Emergency search and rescue

    For product or installation questions, please contact support@rcdrone.top or visit https://rcdrone.top/.

    Details

    CaddxFPV Farsight Analog FPV Camera, Farsight camera features unmatched zoom, AI enhancement, analog output, 1/2" sensor, and compact 19mm design.

    Revolutionary Farsight camera with unmatched zoom, AI enhancer, analog output, 1/2 inch sensor, compact 19mm design.

    CaddxFPV Farsight Analog FPV Camera, FPV camera with 1/2 inch sensor, 1500 TVL resolution, and smart zoom feature for capturing high-quality images.CaddxFPV Farsight Analog FPV Camera, Compact camera and AI box dimensions: 19x19x19.5mm and 33.5x33.5x12.35mm respectively.CaddxFPV Farsight Analog FPV Camera, A camera called CaddxFPV with features like FPV, analog sensor, high TVL, CVBS output and smart zoom capabilities.CaddxFPV Farsight Analog FPV Camera, Device accepts wide voltage input (9-24V) with low power consumption and operates within -20°C to 60°C temperature range.CaddxFPV Farsight Analog FPV Camera, AI-assisted smart zoom offers 1-8X fast magnification with smooth, real-time adjustment.CaddxFPV Farsight Analog FPV Camera, The device has a wide input voltage range of 9-24V and low power consumption, with an operating temperature range of -20 to 60 degrees Celsius.CaddxFPV Farsight Analog FPV Camera, FPV flight, wildlife observation, industrial inspection, search and rescue applications.

    FPV flight, wildlife observation, industrial inspection, search and rescue applications.

    CaddxFPV Farsight Analog FPV Camera, Package includes Caddx Farsight camera, cables, screws, washers, and guide highlighting zoom, size, remote control, and correct orientation for assembly.

    Package includes one Caddx Farsight camera, one Quick Start Guide, one 7Pin3 silicone cable, one 3Pin silicone cable, two each of 5mm, 4mm, and 6mm screws, and two screw washers. The guide highlights features such as fast zoom, hybrid zoom, compact size, and remote control support. Installation instructions stress correct orientation to avoid image inversion. All components are clearly labeled for straightforward assembly.
