2023 New ALZRC Devil 420 Fast FBL 3D Flying RC Helicopter Super Combo With Motor ESC Servo Gyro RC Model toys
-
Detail
ALZRC Devil 420 Super Combo SPECIFICATIONS
Warning: Do not fly it nearby air port
Video Capture Resolution: Other
Type:
Tail shaft diameter: 5mm
Tail rotor diameter: 196mm
Tail blade length: 75mm
State of Assembly: Almost Ready
Remote Distance: 1Km
Remote Control: Yes
Recommend Age: 12+y
Power Source: Electric
Plugs Type: Customized
Package Includes: Original Box
Origin: Mainland China
Motor: Brushless Motor
Model Number: ALZRC Devil 420
Material: Carbon Fiber,Fiberglass,Metal,Rubber,Plastic
Main shaft diameter: 8mm
Main rotor diameter: 935mm
Main blade length: 420mm
Flight Time: Depend on your battery
Features: App-Controlled
Features: Model
Dimensions: 50 x 53 x 180cm
Controller Mode: MODE1,MODE2
Controller Battery: Depend on your transmitter
Control Channels: 6 Channels
Charging Voltage: Depend on your battery
Charging Time: Depend on your battery
Brand Name: uuustore
Aerial Photography: No
ALZRC Devil 420 FAST FBL 3D 3 Rotor Helicopter Kit
Specifications:
ITEM Brand: ALZRC
Item No. Devil 420
Main rotor diameter：935mm
Main blade length：420mm
Tail rotor diameter：196mm
Tail blade length：75mm
Main shaft diameter：8mm
Spindle shaft diamter: 5mm
Tail shaft diameter：5mm
Tail spindle shaft diameter: 3mm
Weight：About 1210g(kit)
Radio transmitter and electronic equipment required for assembly:
1.Transmitter: 6-channel or more,helicopter system
2.Receiver: 6-channel or more
3.Pitch Gauge: Digital Pitch Gauge
4.Battery: 6S/22.2V 1500~2600mAh Li-Po Battery
5.Motor: RMC-BL3120 1000kv 6S Brushless Motor(5mm spindle) x 1
6.ESC: 50~80A Brushless ESC x 1
7.Swashplate Servo: CCPM Micro Digital Metal Servo x 3
8.Tail-lock Servo: Medium Digital Metal Servo x 1
9.Gyroscope: Flybarless Gyro System x 1
10.Other: Plug & Assemble Tools Set
Remark:
The pictures are reference only. Factory may change the design of the product without further notification.Devil 420 FBL KIT Package（Optional color）:
1* ALZRC 380 KitDevil 420 Combo 1 Package（Optional color）:1* ALZRC 380 RC Helicopter Kit1* ALZRC Pentium 60A V4 ESC
1* ALZRC 3120 Pro MotorDevil 420 Combo 2 Package（Optional color）:1* ALZRC 380 RC Helicopter Kit1* ALZRC Pentium 60A V4 ESC
1* ALZRC 3120 Pro Motor1* DM1232S Servo1* DM1531T Servo
1*Mini K-BAR V2 3-Axis Gyro System
Devil 420 FBL KIT
Specification Description AzOmm Tail Rotor Diameter 196mm Tail Blade Length 7Smm Main Shaft Diameter 8mm Spindle shaft dimeter Smm Tail Spindles Shaft Dimeter 3mm Motor Size Maximum 4Imm diameter; maximum height 41mm Battery Compartment AAxAAxI 30mm Weight Appro 12109(KIT) Packing Description Packing ALZRC Devil 420 FAST KIT X 1 Packing Size 55 X 20 * 13cm Packing
Devil 420 Combo 1
Electronic Device EgrL Pentium-60A-V4 3120-PRO 1OOkv Brushless Speed Controller . [BL3120-PRO] Packing Size 54 x 25 X 1Acm Packing Weight 2.5kg Packing Description ALZRC Devil 420 FAST FBL KIT x 1 Packing .
Devil 420 Combo 2
Alzrc Pentium-60A-V4 3120-PRO 10OOkV Brushless Speed Controller . [BL3120-PRO] 3 Co 6 DM12325 DM153IT MINI K-BAR V2 CCPM Micro Digital Metal Servo Medium Digital Metal Locked 3-Axis Gyro System .
-
